fastmatic® Traffic Barrier / Barrier Gate / Boom Gate / Palang Parkir / Portal Otomatis
HIGH SPEED BARRIER
for heavy traffic parking area
vg-900 Series is a specially design system for large commercial parking lots which need a quick treatment of parkers and safety for vehicle and passengers simultaneously.
The system has a 1.0 second of opening time for quick treatment of parkers and 2.0 second of closing time for the safety.
Opening time : 1.0 sec
Closing time : 2.0 sec
Smart breaking : Control based on data from the motor, almost no vibration at the end position
Voltage/ frequency free
No. limit switch
Battery backup operation on power failure
High Speed Intelligent Barrier G400 for commercial parking facility
Unique fast up and safe down movement
The main features G-400 are :
- Opening time 1.0 sec and,
- Closing Time 2.0 sec.
- Almost no vibration of the bar at the end positions.
- Minimized heat & noise, high efficiency epsilon motor.
- Frequency free, usable at any fequency of power without additional setting.
- Intelligent control of optimum acceleration and deceleration.
- No limit switch.
Housing :
- Cold Rolled sheet steel of 2mm thickness
- Zinc plating with powder coating finished
Mechanism :
- Direct connection of the motor and driving shaft
- Zinc plate finish of the lever and body
Technical Specification :
- Bar ( Aluminum Round Profile 3.0M)
- Opening Time 1.0 sec
- Closing Time 2.0 sec
- Frequency & Voltage ( free)
- Power Consumption ( max 200 watt)
- Dimension ( wxdxh) 350x350x1035 ( mm)
- Weight ( not incl boom) 58 Kgs
- Drive ( Inverter Motor = BLDC)
Kami adalah perusahaan yang telah berpengalaman lebih dari 15 tahun sebagai distributor tunggal dan installasi produk-produk berkualitas NICE dari Italia.
Kami juga melayani penjualan produk kami mulai dari kota
Jakarta,
Tangerang,
Bogor,
Bekasi,
Surabaya,
Yogyakarta,
Bandung,
Medan,
Pekan Baru,
Palembang,
Semarang,
Semarang,
Depok,
Bitung,
Cikupa,
Karawaci,
Bintaro,
Bogor,
Jawa Barat,
Jababeka,
Jawa Timur,
Riau,
Dumai,
Kota Modern,
Serpong,
BSD,
Alam Sutera,
Karawang,
Manado,
Jayapura,
Jambi,
Kupang,
Sulawesi,
Makasar,
Irian Jaya hingga
Merauke dengan jaminan
kualitas NICE buatan Italia untuk
kantor,
pabrik,
mall/plaza,
rumah sakit,
gedung pemerintahan atau
swasta.
Hubungi kami sekarang juga untuk informasi pemasangan produk-produk seperti Pintu Kaca Otomatis, Automatic Gate, Automatic Door atau Barrier Gate dan produk otomatis lainnya.
